factory led screen p3.91 panels 7kg suspension standing 4500CD
brightness rental portable tv waterproof videos outdoor digital
signage and displays
Product introduce:
1. Front and rear maintenan,Fast hard connection.
2. Lightweight:500*500mm box weight is only 7 kg,500*1000mm box weight
is only 11.4 kg.
3.High degree of protection,high durability.
3. Quickly connect the upper and lower and left and right positions
of the box, seamless splicing, improving installation efficiency.
4. Eight boxes can be assembled into a cylinderwith a minimum diameter
of 1.3 meters.
Product Details:
1.36 boxes can be assembled into a cylinder witha minimum diameter
of 5.8 meters.
2.The maximum arc ofthe inner and outer arcsof the arc box is 10
degrees.
3.High protection level, not afraid of smoke, dust and rain.
4.The arc can be easily adjusted by 士22.59 to achieve a perfect
arc.
5.The entire CP series supportsmutual splicing to meet variousstyling
needs.
Product Parameters:
Cabinet Type | Flexible | Curved | Ruglar |
|---|
Dimension(MM) | 500x500x84mm | 500x500x84mm | 500x1000x84mm |
|---|
Max Power(W) | 200W | 200W | 400W |
|---|
Cabinet Weight(KG) | 7KG | 7KG | 11.4KG |
|---|
Refresh Rate(Hz) | 7680Hz | 7680Hz | 7680Hz |
|---|
Pixel Pitch(MM) | 2.6/2.976/3.91mm |
|---|
Pixel Density(Dot/M²) | 65536 Dot/M² |
|---|
Led Standard | SMD1921 |
|---|
Brightness(CD/M²) | ≥4500CD/M² |
|---|
IP Rate | IP65 |
|---|
View Angle | 120°/140° |
|---|
Cabinet Material | Aluminum Alloy |
|---|
Maintenance | Front Service |
|---|
Grey Level | 14-16 bit |
|---|
Life Span | ≥50000 Hours |
|---|
Working Humidity | 10%~90%RH |
|---|
Working Temperature | 20~60℃ |
|---|
Working Voltage | AC110V/220V |
|---|
What we offer to customer?
Q1.Can I buy samples placing orders?
Yes.Please feel free to contact us.
Q2.How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers
benefit ;
We respect every customer as our friend and we sincerely do
business and make friends with them,
no matter where they come from.
Q3.What's the warranty?
2 years warranty! We will prepare enough spare parts for you, if
there are broken parts,
can be replaced in time without affecting the use of!
Q4.How can I get the price?-We usually quote within 24 hours after
we get your inquiry.
If you are very urgent to get the price, please email us or contact
us in other ways so that we can offer you a quote.
Q5. How about your delivery time?
Generally, it will takes about 10-15 days after receiving your
advance payment.
The specific delivery time depends on the items and the quantity of
your order.
