P2.6 Small Pixel Rental Outdoor LED Video Wall 4K High Brightness
Product Details
1.Ultra-light and Ultra-thin
A single cabinet is only 6.5 KG , thickness is ony 60MM . Light and
handy , easy to install .
2. Screen Position Pin
Each cabinet have two pins both on the top and bottem , help to
insall correctly , and in a safe way to avoid damage to the lamps.
3. Connection Without Black Lines
Bead installation and positioning. Compared to LCD screen it is
more complete.
4.16-Bit Higher Grey Level
Grey level is the decisive factor for displaying the colors . The
higher the grey level , the richer the displayed colors and the
more delicate the picture.
Cabinet Detail
Die-casting Aluminum cabinet. Strong regidity, no deformation, more
accurate splicing , ergonomic structural design easy installation
by one person.
Product Parameters
Type Number | P2.6 |
|---|
Dimension(MM) | 500x500/500x1000MM |
|---|
Max Power(W) | 600WM² |
|---|
Cabinet Weight(KG) | 13KG |
|---|
Refresh Rate(Hz) | 3840Hz / 1920Hz |
|---|
Pixel Pitch(MM) | 2.6MM |
|---|
Led Standard | SMD2121 |
|---|
Pixel Density(Dot/M²) | 14756 Dot/M² |
|---|
Brightness(CD/M²) | ≥5500CD/M² |
|---|
Viewing Angle | 130° |
|---|
IP Rate | IP65 |
|---|
Cabinet Material | Aluminum Alloy |
|---|
Maintenance | Front and Back Service |
|---|
Grey Level | 14-16 bit |
|---|
Working Temperature | 20~60℃ |
|---|
Working Humidity | 10%~90%RH |
|---|
Life Span | ≥50000 Hours |
|---|
Working Voltage | AC110V/220V, 50/60Hz |
|---|
Installation Details
1.Splicing the box into the required size and shape, aligning the
hole with the quick lock to fix the box.
2.Distinguish the power cable and the signal cable, and insert the
power cable and the signal cable into the corresponding places of
the box.
3.Connect the main signal cable and the main power cable to the
computer and the controller, and use it successfully after
debugging the screen.
Screen Usage
Outdoor rental led screen is suitable for corporate events,
exhibitions, theaters, trade show and wedding function and birthday
party and so on. Light and thin appearance can be faster to install, easy to maintain and meet high-end needs.
Advanced materials can increase the service life.High refresh 3840HZ can show smooth video effect. The quality is clear and the colors are bright and distinct.
Package Details
We have carton case, wooden case, flight case to choose
from.Different products will be configured with different
packaging, in order to better protect the screen.
Production process
Our brand has a history of 19 years, a complete production system
and production line. With its own factory, it can realize
mechanical automation production and reduce manual errors. Truly
achieve high quality and low price, and provide customers with the
best products at the lowest price.
Shipping Details
Provide multiple modes of transportation such as sea, land, air and
so on. We have a long-term cooperative international logistics
company, and our products can be sold all over the world. So far
our products have been sold to more than 150 countries and regions
around the world.
