Customized Waterproof P3.91/P4.81/P5/P6mm Indoor Outdoor LED
Display Screen LED Video Wall 3D led screen
Product feature:
1): Ultra thin, Light weight;
2): Golden-Pleated Connecting seat;
3): Front maintenance;
4): Aluminum alloy material;
product introduce:
1)thichness only 85MM; 500*500mm cabinet only 7.2KG; 500*1000mm
cabinet only 12KG.
2)Using gold-plated connecti on seat, the signal is more stable
Foolproof design to reduce installation error rate.
3)Strong rigidity, oxidation resistance,not easy to deform,
smoother splicing.
4)Support hoisting, leasingtruss installation, frame fixed
installation.
Product parameter
| Dimension(MM) | 500*500*85mm/500*1000*85mm |
| Max.Power(w) | 100W/200W |
| Cabinet Weight(KG) | 7.2KG/12KG |
| Brightness(CD/m²) | ≥600 CD/㎡ |
| LED Standard | SMD2020 |
| Viewing Angle | 120° |
| Protection Level | IP50 |
| Refresh Rate(Hz) | 1920Hz/3840Hz |
| Pixel Pitch(MM) | 2.6/2.98MM |
| Scan Mode | 1/16Scan |
| Pixel Density(Dot/㎡) | 65536 Dot/m² |
| Cabinet Material | Aluminum Alloy |
| Maintenance Method | Front Maintenance |
| Grey Level | 12-16 Bit |
| Working Temperature | -20~60℃ |
| Working Humidity | 10%-90%RH |
| Life Span | ≥50000 Hours |
| Working voltage | AC 110W/220V,50V60HZ |
Charming Co., ltd has always been committed to technical innovation
and service of global entertainmet lighting & LED.
In 2003, the world's first led display was brought into the field
of the entertainmnet applications, and contiunes to lead the trend
of LED's in this field. It has developed into the first brand of
customer satisfaction in China's entertainment lighting Led.
It has obtained nearly 100 patents and obtained ISO9001, CCC, CE,
CB, ROHS, SASO and other certifications.
Adhering to the corporate philosophy of " Charming Achieve Beauty
", we have an international standard full-automatic led display
production line with a factory area of more than 10,000 sqm. We
have provided quality products and services to customers in more
than 150 countries and regions for 20 years.
Warranty:
We guarantee all our displays, modules, parts for two full years.
During this time, we will replace or amend all our goods for free
if there is something wrong with them. We provide lifetime
maintenance and charge only for the raw materials. We provide
technology training for free, which contains the operation and
maintenance training of the LED screens in the factory. We also
provide the operation manual, software, test report and so on. Any
associated CAD drawing on how to fix up the display and some other
expert suggestion will be provided.
What we offer to customer
1. Can we make any size of led display?
Nope, according the led module size and cabient size, such as
rental outdoor led display, the smallest unit size is:500x1000mm.
2,How to install led display?
We will provide drawings or Teamviewer to help you install.
3,How to order LED display?
Please tell me size of led display,where will the display be used.
4,How to ship?
Normally, the display will be shipped by air and sea, we suggest
you go with by sea because it is cheaper.
5,How to finish payment?
You can transfer payment by TT,West union, recommand Trade
Assurance.
